What is a PCB Assembly?

Our PCB Assembly services incorporate both SMT (Surface Mount Technology) and THT (Through-Hole Technology). They are supported by ruggedization services, such as conformal coating and potting, together with extensive test & inspection capabilities.

We support our Customers in both:

High-mix Low-volume (HMLV) PCB Assembly series typically includes tens to hundreds of product versions and/or configurations and production batches ranging from one unit to a thousand pieces.

Low-volume High-mix (LMHV) PCB Assembly series – batches ranging from thousands to tens of thousands of pieces.

Our core strengths come from the ability to manage high-complexity projects, due to a strong focus on quality management and operational excellence. Our Customers benefit from PCB Assembly China with wide organizational skills, engineering and test competencies, as well as advanced supply chain management & planning solutions.

PCB Manufacture and Assembly is in line with IPC Class 2 & Class 3, with a certified IPC trainer in-house, as well as offer both lead-free (RoHS) and leaded manufacturing capabilities

PCB Assembly process competencies:

1. Traceability

XHT utilizes an in-house developed MES (Manufacturing Execution System) system, that supports:

• Traceability
• Directly integrated with the ERP system & production equipment, allowing for online data interchange
• Paperless documentation & revision management
• Real-time production execution visibility

• Workmanship

• XHT complies with IPC standard Class 2 & Class 3 requirements - key manufacturing standards for the electronic assembly services industry.
• All our employees are continuously trained according to IPC training programs. We have access to an IPC trainer onsite.

• Lead-time Management

Our modified daily run MRP2 loop and planning competencies, allow us to minimize electronics assembly material lead times, cover unexpected additional orders from your Customers, as well as minimize the risks of delays.

• Prototyping

We deliver PCBA service prototype builds for our Customers. This is accompanied by product evaluation services (eg. DfM, component engineering), as well as procurement services.

• Conformal Coating

• Working in harsh environments requires adequate protection. We support our Customers with:
• Selective Conformal Coating (spray width control)
• Potting (electronically controlled doses of epoxy/polyurethane)

• Test & Inspection

Our printed circuit board assembly service includes inspection & test capabilities:

• Inspection: inline 3D AOI & 3D SPI, X-Ray
• Test: Functional, In-circuit (ICT), Safety (Burn-in, Hi-Pot) and Environmental (Climate Control / Shock)

Core Capabilities & Technology

At XHT, we possess the following core technical capabilities. We continuously expand our competencies, in order to support our Customers with the higher quality levels of printed circuit board assembly (PCBA), box build, systems integration, and supporting services.

Product Packaging:

The EMS PCB Assembly product will be packaged securely in anti-static bags and placed in a sturdy cardboard box with protective foam inserts.

Shipping:

We offer worldwide shipping for the EMS PCB Assembly product. Shipping options include standard, expedited, and express delivery. Customers can choose their preferred shipping method during the checkout process.

All shipments will be tracked and customers will receive a tracking number once the product has been shipped. Shipping fees will be calculated at checkout based on the destination and selected shipping method.

FAQ:

Q1: What service do you have?
XHT: We provide turnkey solutions including PCB design, Software development, PCB Assembly, Enclosure design, Mold-making, Plastic injection, Finish product assembly, and function testing.
Q2: What are the main products of your PCB/PCBA services?
XHT: Our PCB/PCBA services are mainly for industries including Industrial control, Home appliances main boards, automotive electronics, Consumer electronics, Medical equipment, bank equipment, smart home, etc.
Q3: Is XHT a factory or trade company?
XHT: XHT is a 20-year experienced professional contract manufacturer to provides a stop Turnkey PCB assembly and electronics manufacturing service.
Q4: Can we inspect quality during production?
XHT: Yes, we are open and transparent on each production process with nothing to hide. Customers are welcome to inspect our production process and check in-house.
Q5: How can we ensure our information should not let the third party see our design?
XHT: We are willing to sign an NDA effect by customer side local law and promise to keep customers' data in high confidential level.
Q6: What files are required to get a quotation from you?
XHT: For OEM PCBA projects, please provide the Gerber data/files and an indication of related technical requirements as well as any special requirements if you have them; For ODM projects, please provide a Function List, so our engineering team can work on it.
Q7: What is the standard delivery term?
XHT: Delivery terms of EXW, FCA, FOB, DDU, etc. are all available based on each quote.
Q8: How long does it take for a PCBA quote?
XHT: Depends on the project's complexity. Normally 1-2 weeks is enough for our engineers to evaluate.
Q9: Do you have any minimum order quantity (MOQ) requirements?
XHT: No, we do not have MOQ requirements, we can support your projects starting from prototypes to mass productions.

Tell us your requirements about the FAQ by CLICKING HERE, so that we can provide a solution to save your budget and meet your needs!

We also have a strong supply chain for sourcing electronic materials, which can help you reduce costs by 15%-45%.
