Product Introduction
We provide professional design, manufacturing and assembly services for lithium iron phosphate (LiFePO4) battery systems with different capacities such as 6kWh, 10kWh, 15kWh, 20kWh, 25kWh, especially supporting configurations of 12V, 24V, 48V, 51.2V voltages and 50Ah to 500Ah. These battery systems are widely used in energy storage, electric vehicles, uninterruptible power supplies (UPS), solar energy systems and other fields. The following are the main features and services of this type of lithium battery:
Main features
Battery parameters
Multiple capacity options:
- Provide 6kWh, 10kWh, 15kWh, 20kWh, 25kWh and other capacity options to meet the needs of different application scenarios.
Multiple voltage levels:
- Support multiple voltage levels such as 12V, 24V, 48V, 51.2V, suitable for different electrical systems.
Multiple capacity levels:
- Provide multiple capacity levels such as 50Ah, 100Ah, 150Ah, 200Ah, 280Ah, 300Ah, 400Ah, 500Ah, etc. to ensure flexible configuration.
High performance and safety
Long life:
- Using high-performance LiFePO4 batteries, the cycle life can reach more than 3,000 times, ensuring long-term stable operation.
High safety:
- Built-in multiple protection mechanisms such as overcharge, over-discharge, and short-circuit protection to ensure the safety and reliability of the system.
Wide temperature operating range:
- Supports an operating temperature range of -20°C to +60°C to adapt to various environmental conditions.
Intelligent management system
BMS battery management system:
- Built-in advanced BMS (Battery Management System) to monitor the battery status in real time to ensure the consistency of each battery cell.
Communication interface:
- Supports communication protocols such as RS485, CAN, Modbus, etc., which is convenient for remote monitoring and management.
Environmental protection and high efficiency
Environmentally friendly materials:
- Use environmentally friendly materials to reduce the impact on the environment.
Efficient charging:
- Supports fast charging, shortens charging time, and improves usage efficiency.
Miniaturization and modular design
Compact structure:
- Optimized design, miniaturization and lightweight, easy to install and transport.
Modular design:
- Supports modular expansion, convenient to add or reduce battery modules according to needs.
| Model | BR48100A | BW-48230A | BW-48304A |
| Nominal Voltage | 51.2V | 51.2V | 51.2V |
| Nominal Capacity | 100Ah | 230Ah | 304AH |
| Energy | 5120Wh | 11776Wh | 15360wh |
| Series or Parallel Connection | 16S1P | 16S1P | 16S1P |
| Maximum Charge Current | 100A | 200A | 200A |
| Charge Current (-20 to - 10 ºC) | ≤0.05C | ≤0.05C | ≤0.05C |
| Recommended Charge Voltage | 56V-57.6V | 56V-57.6V | 56V-57.6V |
| BMS Charge Voltage Cut-Off | 57.6V (3.75±0.025vpc) | 57.6V (3.75±0.025vpc) | 57.6V (3.75±0.025vpc) |
| Reconnect Voltage | 54.6V (3.34 ±0.05vpc) | 54.6V (3.34 ±0.05vpc) | 54.6V (3.34 ±0.05vpC) |
| Dimensions (L x W x H) | 440*435*222mm (17.3x17.1x8.74”) | 480*248*618mm | 475*255*770mm |
| Weight | 70KG with wooden packing | :116KG with wooden packing | 138KG with wooden packing |
| Communication Interface | RS485 (Optional) | RS485 (Optional) | RS485/CAN (Optional) |
| Case Material | Metal | Metal | Metal |
| Enclosure Protection | IP54 | IP54 | IP54 |
| Maximum Continuous Discharge Current | 100A | 200A | 200A |
| BMS Discharge Current Cut-Off | 105A | 230A | 230A |
| Reconnect Voltage | 45V | 45V | 45V |
| Discharge Temperature | -20 to 60ºC (-4 to 140 ºF) | -20 to 60ºC (-4 to 140 ºF) | -20 to 60ºC (-4 to 140 ºF) |
| Charge Temperature | 0 to 45ºC (32 to 113 ºF) | 0 to 45ºC (32 to 113 ºF) | 0 to 45ºC (32 to 113 ºF) |
